Leuze Brand Diffuse sensor with background suppression HT46CL2/4P-M12
● In Stock
Part no.: 50134608
Product Description
| Series |
46C |
| Operating principle |
Diffuse reflection principle with background suppression |
| Black-white error |
< 10% up to 1000 mm |
| Operating range, white 90% |
0.05 ... 1 m |
| Operating range, gray 18% |
0.07 ... 0.75 m |
| Operating range, black 6% |
0.09 ... 0.6 m |
| Operating range limit |
0.05 ... 1.2 m |
| Adjustment range |
120 ... 1,200 mm |
| Light source |
Laser, Red |
| Laser class |
2, IEC/EN 60825-1:2014 |
| Protective circuit |
Polarity reversal protection
Short circuit protected
Transient protection |
| Supply voltage UB |
10 ... 30 V, DC, Incl. residual ripple |
| Residual ripple |
0 ... 15 %, From UB |
| Open-circuit current |
0 ... 30 mA |
| Number of digital switching outputs |
2 Piece(s) |
| Switching element |
Transistor, PNP |
| Switching principle |
Light switching |
| Switching element |
Transistor, PNP |
| Switching principle |
Dark switching |
| Switching frequency |
500 Hz |
| Response time |
1 ms |
| Type of connection |
Connector |
| Thread size |
M12 |
| Material |
Plastic |
| No. of pins |
4 -pin |
| Dimension (W x H x L) |
20.5 mm x 76.3 mm x 44 mm |
| Housing material |
Plastic |
| Plastic housing |
PC-PBT |
| Lens cover material |
Plastic / PMMA |
| Net weight |
60 g |
| Type of fastening |
Through-hole mounting
Via optional mounting device |
| Compatibility of materials |
ECOLAB |
| Operational controls |
Multiturn potentiometer |
| Ambient temperature, operation |
-40 ... 60 °C |
| Degree of protection |
IP 67
IP 69K |
| Protection class |
III |
| Certifications |
c UL US |
| Standards applied |
IEC 60947-5-2 |
